We supply the AHBLG-700 square cross flow GRP cooling tower directly from our Chinese manufacturing plant to global B2B buyers, targeting demanding applications such as induction furnace cooling, plastic injection molding heat removal, and data center chilled water systems. Unlike traditional counterflow designs, our cross flow configuration allows gravity-fed water distribution over large fill surfaces, reducing pump head requirements by up to 15% and cutting annual energy costs significantly. Every unit undergoes a 100% factory performance test under simulated load conditions before shipment, and our in-house engineering team provides free 3D layout drawings, seismic anchoring calculations, and remote commissioning support, ensuring seamless integration into your existing pipeline network.
Hebei Fortis Technology Co., Ltd Produktbroschüre
Product Advantages
Gravity-Fed Cross Flow Design Reduces Pumping Energy by 15%
Unlike counterflow towers that require high-pressure spray nozzles to push water upward against airflow, the AHBLG-700 employs a natural gravity distribution basin over the fill media. Water flows vertically downward by gravity while air moves horizontally across the fill, significantly lowering the required pump head. This translates to a 12–15% reduction in circulating pump energy consumption compared to equivalent counterflow models, directly cutting your annual operational electricity costs—a critical ROI factor for continuous-process industries like steel rolling or chemical synthesis.
Premium GRP Casing Ensures 20+ Years of Corrosion-Free Service
The entire shell, fan stack, and cold-water basin are molded from high-grade glass-reinforced plastic with UV-stabilized resin and flame-retardant additives (ASTM E-84 Class 1). This material inherently resists acid rain, saline mist (suitable for coastal installations), and chemical fumes from nearby process vents—problems that rapidly degrade galvanized steel towers. For export shipments crossing oceanic routes, the GRP construction also eliminates rust contamination risks during container transit, ensuring your unit arrives in pristine condition without requiring expensive anti-rust coatings or touch-up painting upon installation.
Large-Face Fill with Anti-Clogging Geometry for Dirty Water Applications
The AHBLG-700 is equipped with high-efficiency PVC fill featuring a wide-flute, wave-shaped profile specifically designed for industrial recirculating water that may contain suspended solids, algae, or scale particles. The cross flow arrangement allows debris to be flushed downward with the water stream rather than trapped between fill layers (a common failure point in counterflow towers). This self-cleaning characteristic extends maintenance intervals from quarterly to bi-annual, and our fill material includes built-in biocidal additives to inhibit Legionella and biofilm growth, meeting WHO guidelines for open recirculating systems.
Parameter Specifications
|
|
||||||||||
|
Product |
Square Cross Flow Cooling Tower |
|||||||||
|
Model |
τ=28℃ |
Main Dimensions (mm) |
Air Volume m³/h |
Fan Diameter (mm) |
Motor Installed Capacity (kw) |
Weight (t) |
τ=28℃ |
Noise at standard point |
||
|
Total Height |
Length× |
self-weight |
operating weight |
|||||||
|
AHBLD/HBLD-300 |
300 |
4514 |
7250× 3810 |
167000 |
3400 |
7.5 |
5.85 |
13.38 |
/ |
59.0 |
|
AHBLD/HBLD-500 |
500 |
5230 |
8033× 4650 |
260000 |
4200 |
11.0 |
9.2 |
17.24 |
/ |
61.5 |
|
AHBLD/HBLD-700 |
700 |
5319 |
8930× 6640 |
370000 |
5000 |
18.5 |
12.95 |
26.05 |
/ |
62.6 |
|
AHBLCD/HBLCD-300 |
300 |
6230 |
10650× 3810 |
167000 |
3400 |
7.5 |
7.05 |
14.18 |
/ |
52.5 |
|
AHBLCD/HBLCD-500 |
500 |
7030 |
11640× 4650 |
260000 |
4200 |
11.0 |
10.8 |
18.84 |
/ |
53.7 |
|
AHBLCD/HBLCD-700 |
700 |
7180 |
12540× 6640 |
370000 |
5000 |
18.5 |
14.75 |
26.81 |
/ |
54.5 |
|
AHBLG/HBLG-300 |
/ |
4514 |
7250× 3810 |
200000 |
3400 |
11.0 |
6.13 |
13.66 |
300 |
64.5 |
|
AHBLG/HBLG-500 |
/ |
5230 |
8033× 4650 |
320000 |
4200 |
18.5 |
9.42 |
17.46 |
500 |
65.0 |
|
AHBLG/HBLG-700 |
/ |
5319 |
8930× 6640 |
450000 |
5000 |
30.0 |
13.19 |
26.29 |
700 |
66.0 |
|
The standard point noise is measured at a distance equal to the equivalent diameter of the air inlet window or its shield equivalent diameter, and 1.5 meters above the ground. The equivalent diameter Dₘis calculated by the formula: Dₘ= 1.13×Length×Width |
||||||||||
|
Features |
The FRP cooling tower serves not only as a temperature regulator but also delivers an efficient, durable, and maintenance-free solution with optimized lifecycle costs. By harnessing the unique properties of FRP materials, it fundamentally addresses the critical challenges of corrosion and lifespan limitations in harsh operating environments, making it the go-to choice for cooling systems in modern industrial and commercial facilities. |
|||||||||
|
Application
|
Central air conditioning system: refrigeration station for commercial buildings, hotels and hospitals. |
|||||||||
|
Industrial refrigeration: process cooling for food processing, chemical, pharmaceutical and plastic industries. |
||||||||||
|
Power industry: auxiliary cooling system for thermal power plant and nuclear power plant. |
||||||||||
|
Manufacturing industry: circulating water cooling for metallurgical and mechanical processing plants. |
||||||||||
|
Data center: Provides cooling water for server rooms. |
||||||||||
|
Payment |
T/T, Western Union. |
|||||||||
|
Service |
Customize and design the size and style according to requirements |
|||||||||
