This page serves global buyers seeking durable, corrosion-proof FRP horizontal storage tanks for critical applications including chemical reagent holding, municipal wastewater equalization, and diesel/gasoline bulk fuel farms. As a China-based export supplier, we combine ISO-certified helical filament-winding and hand lay-up processes to produce tanks from 1m³ to 150m³, with optional secondary containment, UV-resistant gelcoat, and flanged nozzles per ASTM D3299. Our advantage lies in short production cycles (15–25 days), flexible customization for ASME or local pressure specs, and consolidated sea freight logistics to the Middle East, Southeast Asia, Africa, and South America. Every tank undergoes 100% hydrostatic and spark testing before shipment, ensuring zero leakage and 20+ years of service life in aggressive soil or above-ground conditions.
Hebei Fortis Technology Co., Ltd Produktbroschüre
Product Advantages
Superior Corrosion Resistance for Aggressive Media
Our FRP horizontal tanks are engineered with isophthalic or vinyl ester resins specifically selected to withstand highly corrosive contents—including sulfuric acid, sodium hypochlorite, ferric chloride, and crude oil brines. Unlike carbon steel or stainless steel, FRP does not pit or rust, even in continuous immersion or high-humidity environments. This chemical inertness ensures your stored medium remains uncontaminated, extending both tank life and process reliability.
Exceptional Strength-to-Weight Ratio Reducing Installation Costs
Weighing approximately 75% less than equivalent steel tanks, our horizontal FRP vessels significantly lower crane, foundation, and transportation expenses. The lightweight construction allows for easier maneuvering into tight plant layouts or remote job sites without heavy lifting equipment. Despite this low weight, the helical filament-winding process delivers high hoop and axial strength, enabling burial depths of up to 1.5 meters or above-ground span support with minimal deflection.
Customizable Design for Site-Specific Requirements
Every project receives a tailor-made solution. We customize diameters (up to 4 meters), lengths, wall thicknesses, nozzle positions, flanges (ANSI/DIN/JIS), and internals such as baffles, heating coils, or agitation rings. Optional secondary containment (double-wall) meets EPA spill prevention requirements, while UV-resistant gelcoats and anti-static conductive liners are available for flammable fuels or outdoor installations in tropical/desert climates.
Parameter Specifications
|
Product |
Horizontal Storage Tank |
|||
|
F=D/4 |
||||
|
Model |
Volume(m³) |
Diameter(mm) |
Height(mm) |
Number of Supports N1 |
|
FT-HST1 |
1 |
1000 |
1450 |
2 |
|
FT-HST2a |
2 |
1000 |
2730 |
3 |
|
FT-HST2b |
2 |
1200 |
1990 |
2 |
|
FT-HST2c |
2 |
1400 |
1560 |
2 |
|
FT-HST3a |
3 |
1000 |
4010 |
4 |
|
FT-HST3b |
3 |
1200 |
2870 |
2 |
|
FT-HST3c |
3 |
1400 |
2200 |
2 |
|
FT-HST4a |
4 |
1200 |
3760 |
3 |
|
FT-HST4b |
4 |
1400 |
2850 |
3 |
|
FT-HST5 |
5 |
1400 |
3500 |
3 |
|
FT-HST6 |
6 |
1600 |
3300 |
2 |
|
FT-HST7 |
7 |
1600 |
3800 |
3 |
|
FT-HST8a |
8 |
1600 |
4300 |
3 |
|
FT-HST9 |
9 |
1600 |
4780 |
3 |
|
FT-HST10a |
10 |
1600 |
5300 |
3 |
|
FT-HST10b |
10 |
2000 |
4250 |
3 |
|
FT-HST11a |
11 |
1600 |
5800 |
4 |
|
FT-HST11b |
11 |
2000 |
4640 |
3 |
|
FT-HST12a |
12 |
1600 |
6280 |
4 |
|
FT-HST12b |
12 |
2000 |
5040 |
3 |
|
FT-HST12c |
12 |
2200 |
3540 |
2 |
|
FT-HST15a |
15 |
2000 |
6220 |
3 |
|
FT-HST15b |
15 |
2200 |
4330 |
2 |
|
FT-HST15c |
15 |
2400 |
3750 |
2 |
|
FT-HST18a |
18 |
2000 |
7400 |
4 |
|
FT-HST18b |
18 |
2200 |
5120 |
2 |
|
FT-HST18c |
18 |
2400 |
4410 |
2 |
|
FT-HST20a |
20 |
2000 |
8190 |
4 |
|
FT-HST20b |
20 |
2200 |
5650 |
3 |
|
FT-HST20c |
20 |
2400 |
4850 |
2 |
|
FT-HST20d |
20 |
2600 |
4220 |
2 |
|
FT-HST25a |
25 |
2000 |
8310 |
4 |
|
FT-HST25b |
25 |
2200 |
6960 |
3 |
|
FT-HST25c |
25 |
2400 |
5960 |
2 |
|
FT-HST25d |
25 |
2600 |
5160 |
2 |
|
FT-HST25e |
25 |
2800 |
3740 |
2 |
|
FT-HST30a |
30 |
2200 |
8280 |
4 |
|
FT-HST30b |
30 |
2400 |
7060 |
3 |
|
FT-HST30c |
30 |
2600 |
6100 |
3 |
|
FT-HST30d |
30 |
2800 |
4560 |
2 |
|
FT-HST30e |
30 |
3000 |
4100 |
2 |
|
FT-HST35a |
35 |
2400 |
8170 |
3 |
|
FT-HST35b |
35 |
2600 |
7050 |
3 |
|
FT-HST35c |
35 |
2800 |
5370 |
2 |
|
FT-HST35d |
35 |
3000 |
4820 |
2 |
|
FT-HST40a |
40 |
2400 |
9270 |
3 |
|
FT-HST40b |
40 |
2600 |
7990 |
3 |
|
FT-HST40c |
40 |
2800 |
6180 |
2 |
|
FT-HST40d |
40 |
3000 |
5520 |
2 |
|
FT-HST50a |
50 |
2600 |
9870 |
4 |
|
FT-HST50b |
50 |
2800 |
6990 |
2 |
|
FT-HST50c |
50 |
3000 |
6240 |
3 |
|
FT-HST60a |
60 |
2800 |
8620 |
3 |
|
FT-HST60b |
60 |
3000 |
7660 |
3 |
|
FT-HST70a |
70 |
2800 |
10240 |
3 |
|
FT-HST70b |
70 |
3000 |
9050 |
3 |
|
FT-HST80a |
80 |
3000 |
10470 |
4 |
|
FT-HST80b |
80 |
3000 |
11880 |
4 |
